Large LCD display with automatic lighting
Digital and analog display possible
Very simple operation through automatic measuring range and menu control
Selective CH4 measurements with clear measurement results
Selective CO2 measurements with clear measurement results
Electrochemical measurement technology for O2, CO, H2S (optional)
Gas analysis during operation ethane and propane from a few ppm
Measurement data storage for inspections, gas analysis and individual measurements
Data storage with GPS coordinates, date and time
Multifunctional uses for gas detection on pipe networks
Determination of damage points in drill / probe holes
Concentration measurements in pipelines
Long operating time thanks to lithium-ion batteries
Integrated GPS receiver with data storage
Integrated bluetooth interface
Free PC software for file transfer
Extremely robust for tough practical use
Robust and lightweight metal housing (aluminum)
Long-term guarantee of 5 years
Individual configuration according to customer requirements

The applications are preset to the required alarm level, pump performance, the measuring ranges and sensor systems are selected automatically according to the selected application. The selection functions can easily be changed and adapted to your requirements. Subsequent changes are possible from a PC.

In order to use the device in conjunction with a PC, there is free display and control software for each device (e.g. for a tablet PC). Of course, the optional wireless connection with the Bluetooth interface is available here.

Technical data

Indication	Illuminated LCD Display
Alarm	Acoustically, optically
Sensors	Semicondutor ppm CH4 Infrared sensor Vol.% CH4 Infrared sensor Vol.% CO2 Electrochemical Vol.% O2 Electrochemical ppm CO/H2S Gas chromatography
Measuring range	1ppm - 2,2 Vol.% CH4 0 - 100 Vol.% CH4 0 - 100 Vol.% CO2 0 - 25 Vol.% O2 0 - 500ppm CO 0 - 100ppm H2S
Gases	flammable gases, carbon dioxide, oxygen, carbon monoxide, hydrogen sulfide
Calibration	Methane, carbon dioxide, oxygen, carbon monoxide, hydrogen sulfide, ethane
Operating temperature	-20° C up to 40° C
Measurement data memory	25 inspections, 40 individual measurements, 64 gas analyzes
Protection class	IP 54
Energy Supply	Li Ion Battery
Operating time	More than 14 hours
Casing	Aluminum, powder-coated
Dimensions	250 x 65 x 120 mm
Gewicht	1500g
Interface	serial RS232, Bluetooth, GPS
